Manufacturer | Model | Type | I/O | Battery | Communication Methods |
---|---|---|---|---|---|
Howen | Hero-TD01-G | IoT | N/A | Yes - Internal Battery |
Model Hero-TD01-G
Type of sensor Uncooled infrared focal plane array
Infrared thermal camera 120 * 90
Thermal measurement range 0.3m-1.2m
Thermal measurement accuracy ± 0.2 ℃
Hardware Processor AI ARM Cortex-A7 quad-core chipset, 4 x high-performance CEVA DSP
OS Linux
Storage 8GB EMMC + 1GB DDR4
LCD 7 inches, resolution 1024 * 600
Camera Sensor Dual 2Mp sensor, low lux
WDR ≥120dB
FoV (Diagonal / horizontal / vertical) 73 degrees / 65 degrees / 40 degrees
Iris F2.0
Focal length 4.3mm
Performance
Anti-electronic screen, video, mask hacker attack
Recognize height 1.2 ~ 2.2 meters, adjustable angle
Detection range 0.5m ~ 2m, adjustable lens
Face library 30,000 (default)
Attendance record 30,000
Face angle horizontal 30 degrees, vertical 30 degrees
Interface Alarm input 2 pieces
Alarm output 1 piece
Access control Expel
Power supply DC12V, 2A (9 -16V DC)
Power consumption Less than 24 W
Ethernet 1 pcs RJ45 10M / 100M Ethernet
Wifi Wi-Fi 2.4G (optional)
USB 1 PC USB 2.0
General
Working temperature -40 ℃ ~ + 60 ℃.
Dimensions 120mm * 226.5mm *
