| Especificación |
|
Entrada video/audio
|
|
Cámara Analógica
|
4-ch HIK wiring sequence analog camera, Max. 1080P |
|
Entrada de Audio
|
Support up to 3 channels of camera audio (channel 2~4) and 1 channel of two-way audio |
|
Audio bidireccional
|
1, integrated in EXT.DEV interface |
|
Salida vídeo/audio
|
|
Salida de audio
|
1 |
|
Salida de Vídeo
|
Main output: 1, integrated in EXT.DEV interface |
|
Parámetros de Codificación/Decodificación
|
|
Compresión de vídeo
|
H.265/H.264 |
|
Compresión de audio
|
G.711a/G.711u/G.722.1/G.726 |
|
Velocidad de bits de audio
|
16 Kbps |
|
Stream Type
|
Video, video & audio |
|
Dual Stream
|
Supported |
|
Frame Rate
|
PAL: 1 to 25fps@1080P; NTSC: 1 to 30 fps@1080P;
PAL: 1 to 25 fps@720P; NTSC: 1 to 30 fps@720P;
|
|
Resolución de codificación
|
Main stream: 1080P/720P/WD1/4CIF
Sub-stream: 720P/WD1/4CIF/2CIF/CIF
|
|
Red inalámbrica
|
|
Wi-Fi
|
WI module: 1 ×FAKRA antenna
WI58 module：1 ×FAKRA antenna,1 × wifi SMA antenna
WIFI Mode：WEP,WPA-personal, WPA2-personal,None
|
|
Marcación 3G/4G
|
Marcación 3G/4G
|
|
Almacenamiento
|
|
SD Card Storage
|
2 × SD card slots, each up to 512 GB
|
|
Auxiliary Interface
|
|
Interfaz de red
|
Rear panel: 1 ×10M/100M RJ45
|
|
Entrada de alarma
|
4 high/low level signal inputs, 1 pulse signal input, 1 BUTTON input
|
|
Salida de alarma
|
2 relay signal outputs
|
|
Entrada de sensor
|
4 high/low level signal inputs
|
|
Puerto Serial
|
1 × RS-232, 1 × RS-485 (integrated in EXT.DEV interface)
|
|
Interfaz USB
|
Front panel: 1 × USB 2.0
|
|
Posicionamiento
|
|
GNSS (Global Navigation Satellite System)
|
GPS (Global Positioning System) & GLONASS (Global Navigation Satellite System), 1 ×FAKRA antenna
|
|
Sensor
|
|
Sensor G
|
Built-in
|
|
Función inteligente
|
| Advanced Driving Assistance System (ADAS) |
Supports detection and alerts for FCW/LDW/SLW/HMW/PCW/TSR
|
|
Driving Status Monitoring (DSM)
|
Support detection and warning for distraction/fatigue/calling/smoking/unfastened seat belt/yawning/leaving post/IR-blocking sunglasses/occlusion detection. Supports A-pillar algorithm and formal attire algorithm switching, as well as left-hand drive and right-hand drive switching.
|
|
Blind Spot Detection (Right)
|
Supports right blind spot detection and alerts
|
|
Driver Identification
|
Supports driver modeling, driver detection & comparison, driver change alerts, abnormal identity detection & reporting, and attendance tracking
|
|
General
|
|
Dimensión del producto
|
184 mm × 134.4 mm × 44 mm (7.2" × 5.29" × 1.73")
|
|
Fuente de alimentación
|
+9 to +36VDC
|
|
Consumo de energía
|
Standby: ≤ 0.5 W
Full load: ≤ 45 W
Note: Without peripheral and storage media ≤ 20 W
|
|
Temperatura de funcionamiento
|
-25 °C to +70 °C (-13 °F to +158°F)
|
|
Condiciones de humedad
|
10% to 95% (non-condensing)
|
|
Método de operación
|
Mouse, IR remote control, Web control, and touchscreen
|
|
Package Dimension
|
250 mm ×210 mm × 160 mm (9.84" × 8.27" ×6.30")
|
|
Con peso del paquete
|
Without Storage Media:1.38 kg (3.05 lb.)
|
|
Weight (Without Storage Media)
|
0.65 kg (1.43 lb.)
|
|
Certificaciones
|
|
EMC
|
FCC (47 CFR Part 15, Subpart B);CE-EMC (EN 50498: 2010); CE-EMC (EN 55032: 2015+A1:2020, EN 50130-4: 2011+A1:2014)
|
|
Seguridad
|
CB (IEC 62368-1:2018); CE-LVD (EN IEC 62368-1:2020 + A11:2020)
|
|
Ambiente
|
CE-RoHS (2011/65/EU and amendment 2015/863/EU)
|
|
Automotriz y ferroviario
|
EN50155((EN 50155:2021 clause 13, EN 50121-3-2:2016+A1:2019, EN45545-2:2020; EN50153:2014+A1:2017+A2:2020; EN ISO:13732-1:2008;EN61373:2010); EN45545 (EN 45545-2:2020 hl3); E-MARK (ECE R10)
|
