| Especificación |
|
Cámara
|
|
Sensor de imagen
|
1/2.7'' Progressive Scan CMOS |
|
Velocidad de obturación
|
1/3 s to 1/100, 000 s |
|
Iluminación mínima
|
0.01 Lux @ (AGC ON) |
|
Lente
|
|
Longitud focal
|
Fixed focal lens, 2.1mm |
|
Apertura
|
F2.1 |
|
Montura del lente
|
M12 |
|
FOV
|
Horizontal FOV: 127°
Vertical FOV: 73°
Diagonal FOV: 137°
|
|
LENTE
|
|
Entrada de Audio
|
1-channel audio
|
|
Entradas de vídeo
|
3-channel video (default: 1 channel; extension: 2 channels)
|
|
Parámetros de Codificación/Decodificación
|
|
Compresión de vídeo
|
H.265,H.264
|
|
Compresión de audio
|
G.711ulaw,G.711alaw,AAC
|
|
Vídeo
|
|
Main stream
|
CH1:
25fps 1080P 1920 × 1080 (default)
25fps 720P 1280 × 720
CH2~CH3:
25fps 720P 1280 × 720 (default)
|
|
Sub- Stream
|
CH1:
25fps 720P 1280×720
25fps 480P 640×480 (default)
CH2~CH3:
25fps 480P 640×480 (default)
|
|
Audio
|
|
Built-in Mic
|
Omnidirectional pickup, frequency response 50-20000 Hz
|
|
Altavoz incorporado
|
Max 1.5 W, with adjustable volume, not less than 70 dB at 1 m distance
|
|
Red inalámbrica
|
|
Wi-Fi Frequency
|
2.4 GHz
|
|
Posicionamiento
|
GPS (Global Positioning System)
GLONASS (Global Navigation Satellite System)
|
|
Imagen
|
|
SNR
|
37.5 dB
|
|
Wide dynamic range
|
Supports WDR
|
|
Configuración de imagen
|
Adjustable brightness, chroma, contrast, color saturation, and sharpness
|
|
OSD
|
Date, Time, GPS, Speed, etc.
|
|
Auxiliary Interface
|
|
Entrada de alarma
|
2
|
|
Ranura para tarjeta SIM
|
1, Industry Micro SIM, Plug-in type
|
|
Interfaz
|
|
Interfaz de energía
|
1, 8-pin BM Male Terminal
|
|
Reset Key
|
1, Pinhole button
|
|
RS-232
|
1
|
|
Transmisión inalámbrica
|
|
Marcar
|
Europe：
FDD-LTE: B1, B3, B5, B7, B8, B20
TDD-LTE: B38, B40, B41
UMTS: B1, B5, B8
GSM/GPRS/EDGE: 900/1800 MHz
Latin America :
FDD-LTE: B1, B2, B3, B4, B5, B7, B8, B28, B66
TDD-LTE: B40
UMTS: B1, B2, B5, B8
GSM/GPRS/EDGE: 850/900/1800/1900 MHz
Warning: The device requires industrial SIM card (MP2). The ordinary SIM card (MP1) is prohibited. We are not responsible for any problem caused by the use of any ordinary SIM card.
|
|
Protocolo de Wi-Fi
|
802.11 b/g/n
|
|
Función inteligente
|
|
Driving Status Monitoring (DSM)
|
Phone Call,Smoking,Inattenention,Fatigue Driving, Video Occlusion, Infrared Blocking Sunglasses, Not Wearing Seat Belt
|
|
Advanced Driving Assistance System (ADAS)
|
Forward Collision Warning (FCW)
Pedestrian Collision Warning (PCW)
Lane Departure Warning(LDW)
Traffic Sign Recognition (TSR)
Headway Monitoring Warning (HMW)
Traffic Light Detection(TLD)
Forward Car Leaving(FCL)
|
|
General
|
|
Sistema
|
Embedded Linux
|
|
Idioma
|
Currently only supports English
*The language includes APP interface language and voice reminder.
|
|
Storage
|
Dual TF Card (up to 512GB for each)
Class10 or above is recommended
|
|
Sensor
|
Six-axis G-Sensor
*Harsh acceleration, Harsh deceleration and Harsh cornering
|
|
Formato de imagen
|
JPEG
|
|
indicador
|
Positioning Status Indicator (GNSS)
Off: no positioning signal
Steady blue: the positioning signal is normal
Recording Status Indicator(REC)
Off: The built-in or extended camera stops / fails
Steady blue: The built-in or extended camera is recording normally
Network Status Indicator (4G)
Off: No 4G signal
Steady blue: 4G signal and the platform connection normal
Flashing blue: 4G signal normal but no platform connection
Wi-Fi Status Indicator
Off: Wi-Fi AP closed
Steady blue: Wi-Fi AP open and APP connection normal
Flashing blue: Wi-Fi AP open but no APP connection
|
|
Nivel de protección
|
IP4X
*The dashcam is not waterproof
|
|
Fuente de alimentación
|
DC 10V~16V/20V~36V ( P＜12W )
|
|
Dimensión del producto
|
123.0 mm×85.0 mm×38.9 mm (4.8"×3.4"×1.5")
|
|
With Package Dimension
|
223 mm×153 mm×63 mm (8.8"×6.0"×2.5")
|
|
Temperatura de funcionamiento
|
-20°C to 60°C (-4°F to 140°F)
|
|
Condiciones de humedad
|
10% to 95% (non-condensing)
|
|
Peso neto
|
Approx. 270 g (0.6 lb.)
|
|
Con peso del paquete
|
Approx. 900 g (2.0 lb.)
|
